| Power supply |
|
|
Radio frequency
|
870/915 MHz FHSS |
| Performance level of stop (GSS / EMS) |
up to PL d, SIL 2 (EN ISO 13849-1) |
| Performance level of the automatic stop (ATS) |
up to PL d, SIL 2 (EN ISO 13849-1) |
|
Typical working range
|
100 m (330 ft) |
| Max number of functions |
up to 3 multi-axis joysticks, 8 actuators and 4 side buttons;
up to 6 single-axis joysticks, 10 actuators and 4 side buttons |
Average usage time with fully charged battery
(continuous use at 20°C / 68°F) |
without display: 20 hours
with display: 8 hours |
| Protection degree |
IP65 (NEMA 4) |
|
Operating and storage temperature
|
operating: (-20 °C) ÷ (+60 °C) / (-4 °F) ÷ (+140 °F)
storage: (-40 °C) ÷ (+70 °C) / (-40 °F) ÷ (+158 °F) |
| Dimensions |
310×159×173 mm (12.2×6.3×6.8 in) |
| Weight |
~2,8 kg (~ 6.2 lb) |
| Included accessories |
shoulder or waist belt, battery charger, 2 extractable Li-Ion batteries |
